Description
| Size | Ply Rating | LI/SS | Type | Inflated Dimension | Tread Depth | Inflation Pressure | Max. Load Single | Inflation Pressure Dual | Max. Load Dual | Rim Width | ||||
| OD (mm) | SW (mm) | (mm) | Single (psi/kPa) | kgs | lbs | kgs | lbs | kgs | lbs | (Inch) | ||||
| 10.00-20 | 16 | 146/142L | T/T | 1054 | 278 | 13.4 | 115/790 | 3000 | 6610 | 105 | 720 | 2650 | 5840 | 7.50 |
| 12.00-20 | 16 | 152/148L | T/T | 1125 | 315 | 12.0 | 105/720 | 3550 | 7830 | 95 | 660 | 3150 | 6940 | 8.50 |
| 12.00-20 | 18 | 154/150L | T/T | 1125 | 315 | 12.0 | 115/790 | 3750 | 8270 | 105 | 720 | 3350 | 7390 | 8.50 |
