Description
| Size | Ply Rating | LI/SS | Type | Inflated Dimension | Tread Depth | Inflation Pressure | Max. Load Single | Inflation Pressure Dual | Max. Load Dual | Rim Width | ||||
| OD (mm) | SW (mm) | (mm) | Single (psi/kPa) | kgs | lbs | kgs | lbs | kgs | lbs | (Inch) | ||||
| 5.00-8 | 6 | 90/F | T/T | 469 | 146 | 4.7 | 87/600 | 600 | 1320 | 4.00 | ||||
| 6.00-9 | 8 | 126/A2 | T/T | 545 | 160 | 4.8 | 100/690 | 1700 | 3750 | 4.00 | ||||
| 6.00-9 | 10 | 134/A2 | T/T | 545 | 160 | 4.8 | 110/760 | 2120 | 4670 | 4.00 | ||||
| 6.00-9 | 12 | 143/A2 | T/T | 545 | 160 | 4.8 | 130/900 | 2725 | 6005 | 4.00 | ||||
