Description
| SIZE | Ply Rating | LOAD INDEX | Type | Inflated Dimension | Tread Depth (mm) |
INFLATION PRESSURE | MAX .LOAD | MAX.SPEED | Rim Width (Inch) | |||
| Free rolling wheels | Drive wheels | OD(mm) | SW(mm) | psi / kPa | Free rolling wheels | Drive wheels | KPH/MPH | |||||
| 15.0/55-17 TLS[380/55-17] | 10 | 134 | 122 | T/L | 850 | 391 | 24.9 | 38/260 | 2120/4670 | 1500/3305 | 40/25 | 13.00 |
| 15.0/55-17 TLS[380/55-17] | 12 | 138 | 125 | T/L | 850 | 391 | 24.9 | 40/280 | 2360/5200 | 1650/3635 | 40/25 | 13.00 |
| 10.5/80-18 EG | 10 | 131 | 119 | T/L | 885 | 274 | 22.0 | 53/370 | 1950/4300 | 1360/3000 | 40/25 | 9.00 |
| 16 | – | 146 | T/L | 885 | 274 | 22.0 | 85/585 | 4290/9455 | 3000/6610 | 40/25 | 9.00 | |
| 12.5/80-18 EG | 12 | 142 | 129 | T/T | 965 | 308 | 26.8 | 53/370 | 2650/5840 | 1850/4080 | 40/25 | 9.00 |
| 12 | 142 | 129 | T/L | 965 | 308 | 26.8 | 53/370 | 2650/5840 | 1850/4080 | 40/25 | 9.00 | |
| 405/70-24 | 14 | – | 152 | T/L | 1176 | 418 | 33.6 | 70/480 | – | 3550/7825 | 40/25 | 14.00 |
