Description
| SIZE | Ply Rating | LI/SS | Type | Inflated Dimension | Tread Depth (mm) |
INFLATION PRESSURE | MAX .LOAD | MAX.SPEED | Rim Width (Inch) | |
| OD(mm) | SW(mm) | psi / kPa | kgs / lbs | KPH/MPH | ||||||
| 27X8.50-15 EW | 6 | 96B | T/L | 678 | 213 | 13.0 | 45/310 | 710/1570 | 50/30 | 7.00 |
| 27X8.50-15 EW | 8 | 101B | T/L | 678 | 213 | 13.0 | 60/415 | 825/1820 | 50/30 | 7.00 |
| 27X10.50-15 EW | 6 | 98B | T/L | 691 | 259 | 13.0 | 45/310 | 750/1650 | 50/30 | 8.50 |
| 27X10.50-15 EW | 8 | 103B | T/L | 691 | 259 | 13.0 | 60/415 | 875/1930 | 50/30 | 8.50 |
| 10-16.5 EW | 8 | -/A2 | T/L | 773 | 264 | 12.7 | 60/415 | 1880/4140 | 10/5 | 8.25 |
| 10-16.5 EW | 10 | -/A2 | T/L | 773 | 264 | 12.7 | 75/520 | 2135/4710 | 10/5 | 8.25 |
| 12-16.5 EW | 10 | -/A2 | T/L | 831 | 307 | 16.6 | 65/450 | 2540/5600 | 10/5 | 9.75 |
| 12-16.5 EW | 12 | -/A2 | T/L | 831 | 307 | 16.6 | 80/550 | 2865/6320 | 10/5 | 9.75 |
| 14-17.5 EW | 14 | -/A2 | T/L | 921 | 349 | 18.2 | 80/550 | 3875/8540 | 10/5 | 10.50 |
| 15-19.5 EW | 14 | -/A2 | T/L | 1019 | 389 | 18.2 | 70/485 | 4565/10060 | 10/5 | 11.75 |
