Description
| SIZE | Ply Rating | LI/SS | Type | Inflated Dimension | Tread Depth (mm) |
INFLATION PRESSURE | MAX .LOAD | MAX.SPEED | Rim Width (Inch) | |
| OD(mm) | SW(mm) | psi / kPa | kgs / lbs | KPH/MPH | ||||||
| 10-16.5 EG | 6 | -/A2 | T/L | 773 | 264 | 16.6 | 45/310 | 1590/3500 | 10/5 | 8.25 |
| 10-16.5 EG | 8 | -/A2 | T/L | 773 | 264 | 16.6 | 60/410 | 1880/4140 | 10/5 | 8.25 |
| 12-16.5 EG | 8 | -/A2 | T/L | 831 | 307 | 17.0 | 50/340 | 2180/4810 | 10/5 | 9.75 |
| 12-16.5 EG | 10 | -/A2 | T/L | 831 | 307 | 17.0 | 65/450 | 2540/5600 | 10/5 | 9.75 |
