Description
| SIZE | Ply Rating | Type | Inflated Dimension | Tread Depth (mm) |
INFLATION PRESSURE | MAX .LOAD | MAX.SPEED | Rim Width (Inch) | |
| OD(mm) | SW(mm) | psi / kPa | kgs / lbs | KPH/MPH | |||||
| 4.00-6 | 2 | T/T | 345 | 101 | 2.0 | 30/205 | 177/390 | 25/16 | 2.38 |
| 4.00-6 | 4 | T/T | 345 | 101 | 2.0 | 50/345 | 304/670 | 25/16 | 2.38 |
| 4.00-6 | 2 | T/L | 345 | 101 | 2.0 | 30/205 | 177/390 | 25/16 | 2.38 |
| 4.00-6 | 4 | T/L | 345 | 101 | 2.0 | 50/345 | 304/670 | 25/16 | 2.38 |
| 3.25/3.00-8 | 2 | T/L | 365 | 88 | 1.7 | 30/205 | 111/246 | 25/16 | 2.50 |
| 3.25/3.00-8 | 2 | T/T | 373 | 88 | 1.7 | 30/205 | 111/246 | 25/16 | 2.50 |
| 3.50-8 | 2 | T/T | 373 | 86 | 1.8 | 30/205 | 145/320 | 25/16 | 2.50 |
| 3.50-8 | 2 | T/T | 373 | 86 | 1.8 | 50/345 | 195/430 | 25/16 | 2.50 |
| 3.50-8 | 2 | T/L | 373 | 86 | 1.8 | 30/205 | 145/320 | 25/16 | 2.50 |
| 3.50-8 | 4 | T/L | 373 | 86 | 1.8 | 50/345 | 195/430 | 25/16 | 2.50 |
| 4.80/4.00-8 | 2 | T/T | 406 | 101 | 2.5 | 30/205 | 197/435 | 25/16 | 2.50 |
| 4.80/4.00-8 | 4 | T/T | 406 | 101 | 2.5 | 50/345 | 304/670 | 25/16 | 2.50 |
| 4.80/4.00-8 | 2 | T/L | 406 | 101 | 2.5 | 30/205 | 197/435 | 25/16 | 2.50 |
| 4.80/4.00-8 | 4 | T/L | 406 | 101 | 2.5 | 50/345 | 304/670 | 25/16 | 2.50 |
