Description
| Size | Ply Rating | LI/SS | Type | Inflated Dimension | Tread Depth | Inflation Pressure | Max. Load Single | Inflation Pressure Dual | Max. Load Dual | Rim Width | ||||
| OD (mm) | SW (mm) | (mm) | Single (psi/kPa) | kgs | lbs | kgs | lbs | kgs | lbs | (Inch) | ||||
| ST165/80D13 (A78-13) | 4 | 80/76L | T/L | 594 | 165 | 6.2 | 35/250 | 450 | 990 | 35 | 250 | 400 | 880 | 4.50 |
| ST165/80D13 (A78-13) | 6 | 88/83L | T/L | 594 | 165 | 6.2 | 50/350 | 560 | 1230 | 50 | 350 | 487 | 1070 | 4.50 |
| ST185/80D13 (B78-13) | 4 | 84/79L | T/L | 610 | 177 | 7.6 | 35/250 | 500 | 1100 | 35 | 250 | 437 | 965 | 5.00 |
| ST185/80D13 (B78-13) | 6 | 91/87L | T/L | 610 | 177 | 7.6 | 50/350 | 615 | 1360 | 50 | 350 | 545 | 1200 | 5.00 |
| ST185/80D13 (C78-13) | 4 | 87/82L | T/L | 626 | 184 | 7.0 | 35/250 | 545 | 1200 | 35 | 250 | 475 | 1050 | 5.00 |
| ST185/80D13 (C78-13) | 6 | 94/89L | T/L | 626 | 184 | 7.0 | 50/350 | 670 | 1480 | 50 | 350 | 580 | 1280 | 5.00 |
| ST185/80D13 (C78-13) | 8 | 99/95L | T/L | 626 | 184 | 7.0 | 65/450 | 775 | 1710 | 65 | 450 | 690 | 1520 | 5.00 |
| ST195/75D14 (E78-14) | 4 | 90/86L | T/L | 648 | 196 | 7.7 | 35/250 | 600 | 1320 | 35 | 250 | 530 | 1170 | 5.50 |
| ST195/75D14 (E78-14) | 6 | 97/93L | T/L | 648 | 196 | 7.7 | 50/350 | 730 | 1610 | 50 | 350 | 650 | 1430 | 5.50 |
| ST195/75D14 (E78-14) | 8 | 102/98L | T/L | 648 | 196 | 7.7 | 65/450 | 850 | 1875 | 65 | 450 | 750 | 1655 | 5.50 |
| ST205/75D14 (F78-14) | 4 | 93/89L | T/L | 664 | 203 | 7.8 | 35/250 | 650 | 1430 | 35 | 250 | 580 | 1280 | 5.50 |
| ST205/75D14 (F78-14) | 6 | 100/96L | T/L | 664 | 203 | 7.8 | 50/350 | 800 | 1760 | 50 | 350 | 710 | 1570 | 5.50 |
| ST205/75D15 (F78-15) | 4 | 94/89L | T/L | 689 | 203 | 9.0 | 35/250 | 670 | 1480 | 35 | 250 | 580 | 1280 | 5.50 |
| ST205/75D15 (F78-15) | 6 | 101/97L | T/L | 689 | 203 | 9.0 | 50/350 | 825 | 1820 | 50 | 350 | 730 | 1610 | 5.50 |
| ST225/75D15 (H78-15) | 6 | 107/102L | T/L | 719 | 223 | 9.1 | 50/350 | 975 | 2150 | 50 | 350 | 850 | 1870 | 6.00 |
| ST225/75D15 (H78-15) | 8 | 113/108L | T/L | 719 | 223 | 9.1 | 65/450 | 1150 | 2540 | 65 | 450 | 1000 | 2200 | 6.00 |
